29.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats

Min sipariş miktarı : 2 Birim Fiyat : pazarlık edilebilir
Ambalaj bilgileri : Ahşap kasa ve karton kasa Teslim süresi : 7-15 iş günü
Ödeme koşulları : T/T Yetenek temini : Ayda 10000 adet
Menşe yeri: Hunan, Çin Marka adı: Chalong Fly
Sertifika: CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc Model numarası: CLFLE218

Detay Bilgi

Pil Türü:: Lifepo4 Pil Gerilim:: 96V
Kapasite:: 300AH Boyut:: Özelleştirilmiş
OEM/ODM:: Evet Taşıma Paketi:: Köpük ve Kontrplak Kasa
Su Geçirmez Standart:: IP67 HS Kodu:: 8507600090
Özellikler:: uygun maliyetli, hızlı teslimat, Kararlı yapı Başvuru:: elektrikli araç, elektrikli tekne, elektrikli yat, deniz
Vurgulamak:

29.18KWh Marine Lithium Battery

,

Stainless Steel Case LiFePO4 Battery Pack

,

Thermal Management System Lithium Ion Battery

Ürün Açıklaması

OEM ODM LiFePO4 30kwh marine battery pack 96V 300Ah lifepo4 battery for electric boat


If you don't see any products that are matching your requirements please contact us. We may not have it listed on our website yet.


Chalong fly provides ODM&OEMs with assurances of quality for our products and our services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.



29.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 029.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 1

Product Parameter
MODEL
96300
Cell Type - Chemistry
Prismatic- LiFePO4
Rated Capacity
304Ah
Rated Voltage
96V
Energy
29.18KWh
Resistance
30mΩ
Self Discharge
<3% per month
PDU
BMS, 400A relays, fuses, COM socket
Dimensions (L x W x H)
L1300*W500*H380mm
(Can make it smaller if you want)
Weight
2540Kg
Enclosure Protection
IP67 stainless steel case
Discharge Cut-off Voltage
75V
Max Continuous Discharging Current
300A
Peak Discharge Current
400A for 60 seconds
Recommended Discharge Current
300A
Charging Limited Voltage
109.5V
Max Charging Current
200A
Recommended Charge Current
100A
Charge Temperature Range
0~50℃
Discharge Temperature Range
-20~60℃
Recommended Operating Temperature
15~35℃
Available on request
Size, C rate, Communication protocol

29.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 2

29.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 3

29.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 4

Optional thermal management system
liquid cooling and heating system can adapt the battery to different working environment
temperatures .Battery thermal management systems are designed to regulate the temperature of batteries in electric vehicles or other battery-powered systems. It is good in maintaining the overall health and performance of batteries. that helps maintain the optimal temperature to ensure optimal battery performance.

29.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 529.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 629.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 7

29.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 829.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 929.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 1029.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 1129.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 1229.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 1329.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 1429.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 1529.18KWh Marine Lithium Battery with Stainless Steel Case and Thermal Management System for Electric Boats 16


FAQ:

Q1. Are you a factory?

A: Yes, we are a professional lithium battery manufacturer in China, and factory tour is acceptable.


Q2. Do you accept OEM/ODM?

A: Yes, OEM, ODM, LOGO, and STICKER is acceptable, our professional team is on hand to offer you any solutions.


Q3. Can I have a sample order first?

A: Yes, sample order is acceptable.


Q4. How will my order be shipped?

A: Chalong Fly offers a variety of shipping methods, such as DHL, UPS, FedEx, TNT, Airline and sea shipping.


Q5: What kind of certificates do you have?

A: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3, UL, etc.


Q6. Can we sign a NDA in order for a long-term cooperation?

A: Yes, the client’s requirements is respected.


O7: Is there any warranty or After-Sale Service?

A: We will check each battery before shipment, and 100% high quality guaranteed. The warranty is about 1~20 years depends on different models.


Q8. Why do you choose Chalong Fly?

A: Chalong Fly R&D center has more than 60 R&D engineers, 12 of whom have more than 10 years of experience related to power development. We have a deep understanding of power electronics technology, and a full understanding of the needs of the application industry, and have developed many public technology solutions.
